Parts and tools needed for this application:
10 qts oil https://www.fcpeuro.com/products/mercedes-atf-febi-bilstein-002989060309
10 new pan bolts https://www.fcpeuro.com/products/mercedes-automatic-transmission-pan-bolt-genuine-mercedes-0029909503
1 New torque converter bolt https://www.fcpeuro.com/products/mercedes-automatic-transmission-torque-converter-drain-plug-m8-genuine-mercedes-0019901117
New tray may be different depending on the model. Dobble check on model and ask vendor https://www.fcpeuro.com/products/mercedes-at-filter-genuine-mercedes-7252703707
Fill adaptor https://www.fcpeuro.com/products/mercedes-transmission-fill-adapter-722-9-cta-7415
CTA filling system and and service key https://www.jbtools.com/cta-tools-3402-benz-trans-oil-filling-kit/
Guide tube https://www.fcpeuro.com/products/mercedes-guide-tube-genuine-mercedes-7252716100
Overflow pipe https://www.fcpeuro.com/products/mercedes-auto-trans-pan-overflow-pipe-genuine-mercedes-7252712101
Pump tank https://www.fcpeuro.com/products/atf-filling-system-tank-cta-7400

Scanner
E10 for pan bolts
8 mm allen key for pan drain plug (if you don't use the service key)
4 mm allen key for torque converter plug
8mm socket for bottom cover plate
18mm socket for transmission mount bolts (IF NEEDED TO BE REMOVED)
Jack stands/ wood blocks
Floor jacks
Portable lift if possible


Tray position setting points:
Position one = add oil
Position 2 = take oil out a little at the time
Position 3 = adjust oil level
Position 4 = drain oil out


Keep in mind that some fluid will remain in the pan after you drain it.


Fill up transmission temperature at 39C


Pan bolts 4 Nm = 35 in/lbs
Tighten bolts to torque spec, then go 90 degrees or a quarter turn more
Torque converter 10 Nm = 89 in/lbs
Rear engine mount 30 Nm = 22 ft/lbs



List of cars with 9G Tronic:

Mercedes C-Class
2015 – 2021 Mercedes-Benz W205 (all models)
2022 – 2023 Mercedes-Benz W206

Mercedes E-Class
2014 – 2016 Mercedes-Benz W212 (E 350 BlueTec Diesel Technology only)
2016 – 2023 Mercedes-Benz W213 (all models)

Mercedes S-Class
2017 – 2021 Mercedes-Benz W222 (all except V12 models)
2021 – 2023 Mercedes-Benz W223

Mercedes V-Class
2020 – V-Class (W447) (longitudinal engines)

Mercedes GLC-Class
2015 – 2023 GLC

Mercedes-Benz GLE-Class
2016 – 2019 GLE (W166) (except 63 AMG & 350 models)
2020 – GLE (W167) (except 63 models)

Mercedes-Benz GLS-Class
2017 – 2019 GLS (X166) (all except AMG)
2020 – GLS (X167)

Mercedes-Benz SLK-Class
2015 – 2020 SLC (R172) (except 55 AMG)

Mercedes-AMG models
Mercedes-AMG SL
2022 – AMG SL (R232)

Non Mercedes-Benz Models by JATCO as the JR913E

Nissan
2016 - 2020 Titan
2018 - 2020 Frontier
2018 Fuga
2018 Skyline
2023 – Nissan Z
Infiniti

Aston Martin
2021 – Aston Martin DBX V8 and Straight-Six
2022 – Aston Martin DBX707
